MB ASUS B840 AMD S-AM5 9A GEN /4X DDR5 7600 /HDMI /2X DP /2X USB 3.2 /MICRO ATX /GAMA MEDIA

Prime b840m-a las placas base de la serie asus prime están diseñadas por expertos para liberar todo el potencial de los procesadores amd ryzen 9000 series. La placa base prime b840m-a ofrece a los usuarios y a los ensambladores de pc una variedad de optimizaciones de rendimiento a traves de funciones intuitivas de software y firmware. Esta diseñada para ser compatible con pc con ia avanzada, ofreciendo la potencia y la conectividad necesarias para aplicaciones de ia exigentes.

Ficha técnica PRIME B840M-A
CPU AMD SOCKET AM5 FOR AMD RYZEN™ 9000 AND 8000 AND 7000 SERIES DESKTOP PROCESSORS
CHIPSET AMD B840 CHIPSET
MEMORY 4 X DIMM SLOTS, MAX. 256GB, DDR5 - SUPPORTS UP TO 7600+MT/S (OC) WITH RYZEN™ 9000 AND 8000 AND 7000 GRAPHICS 2 X DISPLAYPORT; 1 X HDMI™ PORT
EXPANSION SLOTS:
AMD RYZEN™ 9000 AND 7000 SERIES DESKTOP PROCESSORS*
1 X PCIE 4.0 X16 SLOT (SUPPORTS X16 MODE)
AMD RYZEN™ 8000 SERIES DESKTOP PROCESSORS
1 X PCIE 4.0 X16 SLOT (SUPPORTS X8/X4 MODE)**
AMD B840 CHIPSET
2 X PCIE 3.0 X16 SLOTS (SUPPORT X1 MODE)
STORAGE:
TOTAL SUPPORTS 3 X M.2 SLOTS AND 4 X SATA 6GB/S PORTS
AMD RYZEN™ 9000 AND 7000 SERIES DESKTOP PROCESSORS
M.2_1 SLOT (KEY M), TYPE 2280 (SUPPORTS PCIE 4.0 X4 MODE)
M.2_2 SLOT (KEY M), TYPE 2242/2260/2280 (SUPPORTS PCIE 4.0 X4 MODE)
AMD RYZEN™ 8000 SERIES DESKTOP PROCESSORS
M.2_1 SLOT (KEY M), TYPE 2280 (SUPPORTS PCIE 4.0 X4 MODE)
M.2_2 SLOT (KEY M), TYPE 2242/2260/2280 (SUPPORTS PCIE 4.0 X4/X2 MODE)*
AMD B840 CHIPSET
M.2_3 SLOT (KEY M), TYPE 2280 (SUPPORTS PCIE 3.0 X4 MODE)
4 X SATA 6GB/S PORTS

• SPECIFICATIONS VARY BY CPU TYPES.
  AMD RAIDXPERT2 TECHNOLOGY
  RYZEN™ 9000 SERIES PROCESSORS: RAID 0/1/5/10
  RYZEN™ 8000 SERIES PROCESSORS: RAID 0/1
  RYZEN™ 7000 SERIES PROCESSORS: RAID 0/1/10
  ETHERNET 1 X REALTEK 2.5GB ETHERNET; ASUS LANGUARD
  BACK PANEL I/O PORTS
  2 X USB 10GBPS PORTS (2 X TYPE-A)
  1 X USB 5GBPS PORT (1 X USB TYPE-C®)
  4 X USB 2.0 PORTS (4 X TYPE-A)
  2 X DISPLAYPORT
  1 X HDMI™ PORT
  1 X REALTEK 2.5GB ETHERNET PORT
  3 X AUDIO JACKS
  1 X BIOS FLASHBACK™ BUTTON
  BIOS 256 MB FLASH ROM, UEFI AMI BIOS
  MANAGEABILITY WOL BY PME, PXE
  OPERATING SYSTEM WINDOWS 11, WINDOWS 10 64-BIT
  FORM FACTOR MICRO-ATX FORM FACTOR 9.6 INCH X 9.6 INCH (24.4 CM X 24.4 CM)

Garantía: 3 años
