SWITCH | TP-LINK | SG2005P-PD | 5 PUERTOS GIGABIT | 1 POE++ IN | 4 POE+ | OMADA SMART | PARA EXTERIOR | IP 55 | HASTA 200M DE DISTACIA POE

Sg2005p-pd
switch omada smart de 5 puertos gigabit, 1 poe++ in y 4 poe+ out para exterior distancia poe de hasta 200m. Duplica la distancia de transmisión a velocidad gigabit, perfecto para instalaciones de videovigilancia y puntos de acceso de largo alcance. 1 puerto gigabit poe++ in y 4 puertos poe+ out. Admite hasta 64w / 44w / 19w/ 6w de salida de potencia poe cuando se alimenta con 802.3bt tipo 4 (90w), 802.3bt tipo 3 (60w), 802.3at y 802.3af poe, respectivamente.** certificación ip55, resistente al exterior. Soporta las inclemencias del tiempo como el agua, polvo, rayos uv y rayos 4kv, garantizando un funcionamiento estable. Fácil instalación. Fácil de montar en una pared o poste, kits de montaje incluidos. Integración con omada en la nube. Accede a funcionalidades avanzadas como la gestión centralizada desde la nube, monitorización avanzada, gestión multisitio y funciones como la lista de control de acceso (acl), qos y vlan.

Ficha técnica CARACTERÍSTICAS DE HARDWARE
ESTÁNDARES Y PROTOCOLOS
IEEE 802.3I, IEEE 802.3U, IEEE 802.3AB, IEEE 802.3AD, IEEE 802.3AF, IEEE 802.3AT, IEEE 802.3BT, IEEE 802.3X, IEEE 802.1D, IEEE 802.1S, IEEE 802.1W, IEEE 802.1Q, IEEE 802.1P, IEEE 802.1X
INTERFAZ
• 1× 10/100/1000 MBPS RJ45 POE IN PORTS (COMPLIANCE WITH 802.3AF/AT/BT)
• 4× 10/100/1000 MBPS RJ45 POE OUT PORTS (COMPLIANCE WITH 802.3AF/AT POE)
MEDIOS DE RED
• 10BASE-T: UTP CATEGORY 3, 4, 5 CABLE (MAXIMUM 100M)
• 100BASE-TX/1000BASE-T: UTP CATEGORY 5, 5E OR ABOVE CABLE (MAXIMUM 100M)
CANTIDAD DE VENTILADORES
FANLESS
FUENTE DE ALIMENTACIÓN
OBTAIN POWER FROM 802.3AF/AT/BT POE SOURCE
PUERTOS POE (RJ45)
• POE IN PORT: PORT 5, COMPLIANCE WITH 802.3AF/AT/BT
• POE OUT PORTS: PORTS 1-4, COMPLIANCE WITH 802.3AF/AT POE
• POE POWER BUDGET:
-64 W WHEN POWERED BY 802.3BT TYPE 4 (90 W)
-44 W WHEN POWERED BY 802.3BT TYPE 3 (60 W)
-19 W WHEN POWERED BY 802.3AT
-6 W WHEN POWERED BY 802.3AF
DIMENSIONES
3.9 × 1.5 × 6.7 IN (100 × 38.5 × 170 MM)
CONSUMO DE POTENCIA MÁXIMO
71.5 W (WHEN POWERED BY 802.3BT TYPE 4 (90 W))
DISIPACIÓN MÁXIMA DE CALOR
243.99 BTU/HR (WHEN POWERED BY 802.3BT TYPE 4 (90 W))
RENDIMIENTO
CAPACIDAD DE CONMUTACIÓN
10 GBPS
TASA DE REENVÍO DE PAQUETES
7.44 MPPS
TABLA DE DIRECCIONES MAC
8K
MEMORIA DEL BUFFER DE PAQUETE
4.1 MBIT
JUMBO FRAME
9 KB
CARACTERÍSTICAS DE SOFTWARE
CALIDAD DE SERVICIO
• 802.1P COS/DSCP PRIORITY
• 8 PRIORITY QUEUES
• PRIORITY SCHEDULE MODE

• SP (STRICT PRIORITY)
• WRR (WEIGHTED ROUND ROBIN)
  • QUEUE WEIGHT CONFIG
  • BANDWIDTH CONTROL
• PORT/FLOW-BASED RATING LIMIT
  • SMOOTHER PERFORMANCE
  • STORM CONTROL
• MULTIPLE CONTROL MODES(KBPS/RATIO)
• BROADCAST/MULTICAST/UNKNOWN-UNICAST CONTROL
  CARACTERÍSTICAS L2 Y L2+
  • 32 IP INTERFACES
• SUPPORT IPV4/IPV6 INTERFACE
  • STATIC ROUTING
• 32 IPV4/IPV6 STATIC ROUTES
  • DHCP SERVER
  • DHCP RELAY
• DHCP INTERFACE RELAY
• DHCP VLAN RELAY
  • DHCP L2 RELAY
  • STATIC ARP
  • PROXY ARP
  • GRATUITOUS ARP
  • LINK AGGREGATION
• STATIC LINK AGGREGATION
• 802.3AD LACP
• UP TO 8 AGGREGATION GROUPS AND UP TO 8 PORTS
  PER GROUP
  • SPANNING TREE PROTOCOL
• 802.1D STP
• 802.1W RSTP
• 802.1S MSTP
• STP SECURITY: TC PROTECT, BPDU FILTER/PROTECT,
  ROOT PROTECT
  • LOOPBACK DETECTION
  • FLOW CONTROL
• 802.3X FLOW CONTROL
  • MIRRORING
• PORT MIRRORING
• CPU MIRRORING
• ONE-TO-ONE
• MANY-TO-ONE
• FLOW-BASED
• INGRESS/EGRESS/BOTH
  • DEVICE LINK DETECT PROTOCOL (DLDP)
  • 802.1AB LLDP/ LLDP-MED
  MULTICAST L2
  • 511 IPV4, IPV6 SHARED MULTICAST GROUPS
  • IGMP SNOOPING
• IGMP V1/V2/V3 SNOOPING
• FAST LEAVE
• IGMP SNOOPING QUERIER
• STATIC GROUP CONFIG
  • MULTICAST VLAN REGISTRATION (MVR)
  • MULTICAST FILTERING
  • MLD SNOOPING
• MLD V1/V2 SNOOPING
• FAST LEAVE
• MLD SNOOPING QUERIER
• STATIC GROUP CONFIG
  • LIMITED IP MULTICAST (256 PROFILES AND 16 ENTRIES PER PROFILE)
  CARACTERÍSTICAS AVANZADAS
  • AUTOMATIC DEVICE DISCOVERY
  • BATCH CONFIGURATION
  • BATCH FIRMWARE UPGRADING
  • INTELLIGENT NETWORK MONITORING
  • ABNORMAL EVENT WARNINGS
  • UNIFIED CONFIGURATION
  • REBOOT SCHEDULE
  SOPORTE IPV6
  • IPV6 DUAL IPV4/IPV6
  • MULTICAST LISTENER DISCOVERY (MLD) SNOOPING
  • IPV6 NEIGHBOR DISCOVERY (ND)
  • PATH MAXIMUM TRANSMISSION UNIT (MTU) DISCOVERY
  • INTERNET CONTROL MESSAGE PROTOCOL (ICMP) VERSION 6
  • TCPV6/UDPV6
  • IPV6 APPLICATIONS
• DHCPV6 CLIENT
• PING6
• TRACERT6
• TELNET (V6)
• IPV6 SNMP
• IPV6 SSH
• IPV6 SSL
• HTTP/HTTPS
• IPV6 TFTP
  VLAN
  • VLAN GROUP
• MAX. 4K VLAN GROUPS
  • 802.1Q TAG VLAN
  • MAC VLAN: 12 ENTRIES
  • PROTOCOL VLAN
  • GVRP
  • VOICE VLAN
  LISTA DE CONTROL DE ACCESO
  • SUPPORT UP TO 230 ENTRIES
  • TIME-RANGE
• TIME SLICE
• WEEK TIME-RANGE
• ABSOLUTE TIME-RANGE
• HOLIDAY
  • TIME-BASED ACL
  • MAC ACL
• SOURCE MAC
• DESTINATION MAC
• VLAN ID
• USER PRIORITY
• ETHER TYPE
  • IP ACL
• SOURCE IP
• DESTINATION IP
• IP PROTOCOL
• TCP FLAG
• TCP/UDP SOURCE PORT
• TCP/UDP DESTINATION PORT
• DSCP/IP TOS
  • IPV6 ACL
  • COMBINED ACL
  • RULE OPERATION
• PERMIT/DENY
  • POLICY ACTION
• MIRROR
• RATE LIMIT
• REDIRECT
• QOS REMARK
  • ACL RULES BINDING
• PORT BINDING
• VLAN BINDING
  • ACTIONS FOR FLOWS
• MIRROR (TO SUPPORTED INTERFACE)
• REDIRECT (TO SUPPORTED INTERFACE)
• RATE LIMIT
• QOS REMARK
  SEGURIDAD
  • AAA
  • 802.1X
• PORT-BASED AUTHENTICATION
• MAC (HOST) BASED AUTHENTICATION
• AUTHENTICATION METHOD INCLUDES PAP/EAP-MD5
• MAB
• GUEST VLAN
• SUPPORT RADIUS AUTHENTICATION AND ACCOUNTABILITY
  • IP/IPV6-MAC BINDING
• 512 BINDING ENTRIES
• DHCP SNOOPING
• DHCPV6 SNOOPING
• ARP INSPECTION
• ND DETECTION
  • IP SOURCE GUARD
• 253 ENTRIES
• SOURCE IP+SOURCE MAC
  • IPV6 SOURCE GUARD
• 183 ENTRIES
• SOURCE IPV6 ADDRESS+SOURCE MAC
  • DOS DEFEND
  • STATIC/DYNAMIC/PERMANENT PORT SECURITY
• UP TO 64 MAC ADDRESSES PER PORT
  • BROADCAST/MULTICAST/UNICAST STORM CONTROL
• KBPS/RATIO CONTROL MODE
  • PORT ISOLATION
  • SECURE WEB MANAGEMENT THROUGH HTTPS WITH SSLV3/TLS 1.2
  • SECURE COMMAND LINE INTERFACE (CLI) MANAGEMENT WITH SSHV1/SSHV2
  • IP/PORT/MAC-BASED ACCESS CONTROL
  MIBS
  • MIB II (RFC1213)
  • BRIDGE MIB (RFC1493)
  • P/Q-BRIDGE MIB (RFC2674)
  • RADIUS ACCOUNTING CLIENT MIB (RFC2620)
  • RADIUS AUTHENTICATION CLIENT MIB (RFC2618)
  • REMOTE PING, TRACEROUTE MIB (RFC2925)
  • SUPPORT TP-LINK PRIVATE MIBS
  • RMON MIB(RFC1757, RMON 1,2,3,9)
  GESTIÓN
  OMADA APP
  YES, THROUGH
  • OMADA CLOUD-BASED CONTROLLER
  • OMADA HARDWARE CONTROLLER
  • OMADA SOFTWARE CONTROLLER
  GESTIÓN CENTRALIZADA
  • OMADA CLOUD-BASED CONTROLLER
  • OMADA HARDWARE CONTROLLER
  • OMADA SOFTWARE CONTROLLER
  ACCESO A LA NUBE
  YES, THROUGH
  • OMADA CLOUD-BASED CONTROLLER
  • OMADA HARDWARE CONTROLLER
  • OMADA SOFTWARE CONTROLLER
  APROVISIONAMIENTO SIN CONTACTO
  YES. REQUIRING THE USE OF OMADA CLOUD-BASED CONTROLLER.
  FUNCIONES DE GESTIÓN
  • WEB-BASED GUI
  • COMMAND LINE INTERFACE (CLI) THROUGH TELNET
  • SNMPV1/V2C/V3
  • SNMP TRAP/INFORM
  • RMON (1,2,3,9 GROUPS)
  • SDM TEMPLATE
  • DHCP/BOOTP CLIENT
  • DUAL IMAGE, DUAL CONFIGURATION
  • CPU MONITORING
  • CABLE DIAGNOSTICS
  • EEE
  • SNTP
  • SYSTEM LOG
  OTROS
  CERTIFICACIONES
  CE, FCC, ROHS
  CONTENIDO DEL PAQUETE
  • SG2005P-PD
  • MOUNTING KITS
  • INSTALLATION GUIDE
  REQUISITOS DEL SISTEMA
  MICROSOFT® WINDOWS® 98SE, NT, 2000, XP, VISTA™ OR WINDOWS 7/8/10/11, MAC® OS, NETWARE®, UNIX® OR LINUX.
  FACTORES AMBIENTALES
  • OPERATING TEMPERATURE: -40 TO 60 °C (-40 TO 140 °F)
  • STORAGE TEMPERATURE: -40 °C TO 70 °C (-40 °F TO 158 °F)
  • OPERATING HUMIDITY: 10–90% RH NON-CONDENSING
  • STORAGE HUMIDITY: 5–90% RH NON-CONDENSING

Garantía: 2 años
